Modern Two Layers Leisure Vacation Container House with Open
Balcony
Product Introduction
Container houses are transported in flat packed type by shipping
container, installed in several hours. Then you can own a fully
functional office. Container houses is durable, tough and movable.
house frame includes four columns, upper and lower beams, floor
beams, channel steel structure.
The container body is all-welded structure, with shock resistance,
anti-sag, anti-deformation, waterproof, fire prevention, wind
protection, anti-corrosion.
Seamless welding of walls and ceilings, sealing and waterproofing,
flooring laying with wooden floors, push-pull aluminum alloy glass
windows, stainless steel security nets, lighting, switches, air
conditioning sockets and other facilities in one step, on-site
lifting, ready-to-install .
Product Parameter
Frame
20ft keel (two options) | C100mm*100mm*2.5mm steel purlin C160mm*160mm*3.0mm steel purlin |
40ft keel (two options) | C100mm*100mm*3.0mm steel purlin C160mm*160mm*3.5mm steel purlin |
Wall
insulation material (thickness depends on customer) | 50mm/75mm/100mm/150mm thickness sandwich panel |
| Wall inside | 0.5mm color steel sheet |
| Wall outside | 0.5mm color steel sheet |
| color outside | customer-made |
| color inside | White |
Roof
| outside sheet | 0.5mm steel sheet |
insulation layer (thickness depends on customer) | 50mm/75mm/100mm/150mm thickness sandwich panel |
| keel | C30mm*40mm*3.0mm steel purlin |
| ceiling | 3mm thickness PVC ceiling (light gray) |
Floor
| Floor bottom board | 1.0mm thickness steel sheet |
| insulation layer | 18mm thickness fire protection |
| keel | C30mm*80mm*3.0mm steel purlin |
windows and door
window (20ft 2pcs) (40ft 4pcs) | 900*1200mm |
door (20ft 1pcs) (40ft 3pcs) | 875*2000mm |
Product Features
1)Fast and Efficient
All products and components adopt factory prefabrication,
standardized production, convenient transporation and fast on -
site assembly.
(3 workers, 1 crane, 10-20 units assembled per day)
2) Environment Friendly
Modules are esaily removable at the end of the project making the
site in its initial conditions and appearance. To ensure the
concept of "zero waste" on site.
Product Application
Container office is widely used on a temporary or permanent site,
like construction site, roadside, factory site etc. It can be used
as office, meeting room, sport room etc.
